LED ADJ Rotated Spot Down Light (Eco Premiere Series)
Use Cases :
Restaurant | Hotel | Retail | Office | Commercial | Shopping Mall
Wattage (W):
8W / 15W / 19W /26W / 33W
Color Temperature (CCT):
2700 / 3000 / 4000 / 6500
Color Rendering Index (CRI):
85 / 95
Beam Angle:
15° / 25° / 45° / 60°
Lumen (lm):
700 / 1,300 / 2,350 / 3,350
Luminous Efficacy (lm/w):
88 / 87 / 94/ 96
Material:
Aluminium + Polycarbonate (PC) Milky Diffuser (Option: Clear Diffuser)
Dimension (mm):
Ø: 42 x H: 80 / Ø: 52 x H: 80 / Ø: 62 x H: 85 / Ø: 72 x H: 85 / Ø: 82 x H: 85 / Ø: 110 x H: 130
Cut Hole Size (mm):
55 / 78 / 95 / 120
Weight (gm):
400 / 550 / 600 /750
Ingress Protection (IP):
IP20 / IP44
Lifespan (hrs):
50,000
Driver:
External - Non Dimming / Dimming 1-10V, Phase Cut, DALI
Input Voltage:
220 - 240Vac (50/60 Hz)
Power Factor (PF):
> 0.90
Total Harmonic Distortion (THD):
< 20%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | Ingress Protection (IP) |
|---|---|---|---|---|---|---|
| LS1ARRP▢-A08C▢▢P▢ | 8 | 85 / 95 | 700 | Ø: 68 x H: 85 | 50,000 | IP20 / IP44 |
| LS2ARRP▢-A15C▢▢P▢ | 15 | 85 / 95 | 1,300 | Ø: 85 x H: 105 | 50,000 | IP20 / IP44 |
| LS3ARRP▢-A25C▢▢P▢ | 25 | 85 / 95 | 2,350 | Ø: 108 x H: 125 | 50,000 | IP20 / IP44 |
| LS4ARRP▢-A35C▢▢P▢ | 35 | 85 / 95 | 3,350 | Ø: 140 x H: 155 | 50,000 | IP20 / IP44 |
Interested in this product?
Contact us for more information or request a free on-site consultation using the button below.
