LED AR111 Module
SIRIMSuruhanjaya TenagaBuatan MalaysiaMalaysia BrandIECEE CB SchemeRoHS

LED AR111 Module (Eco Master / Eco Premiere Series)

Use Cases :

Hotel | Retail | Office | Commercial

Wattage (W):

10W / 15W / 19W / 28W

Color Temperature (CCT):

2700 / 3000 / 4000 / 6500

Color Rendering Index (CRI):

85 / 95

Beam Angle:

15° / 25° / 40°

Lumen (lm):

1,000 / 1,500 / 1,900 / 2,800

Luminous Efficacy (lm/w):

100 / 100 / 100 / 100

Material:

Aluminium with Die Cast Housing + Polycarbonate (PC) Clear Diffuser

Dimension (mm):

Ø: 111 x H: 50

Weight (gm):

400

Ingress Protection (IP):

IP20 / IP44

Lifespan (hrs):

50,000

Driver:

External - Non Dimming / Dimming 1-10V, Phase Cut, DALI

Input Voltage:

220 - 240Vac (50/60 Hz)

Power Factor (PF):

> 0.90

Total Harmonic Distortion (THD):

< 20%

view more >

Specification

Part Number Wattage (W) CRI Lumen (lm) Dimension (mm) Lifespan (hrs) IP
LAR111G▢-A10C▢▢▢ 10 85 / 95 1,000 Ø: 111 x H: 50 50,000 IP20 / IP44
LAR111G▢-A15C▢▢▢ 15 85 / 95 1,500 Ø: 111 x H: 50 50,000 IP20 / IP44
LAR111G▢-A19C▢▢▢ 10 85 / 95 1,900 Ø: 111 x H: 50 50,000 IP20 / IP44
LAR111G▢-A28C▢▢▢ 28 85 / 95 2,800 Ø: 111 x H: 50 50,000 IP20 / IP44
