Indoor & Commercial > LED Cylindrical Surface Down Light

LED Cylindrical Surface Down Light
SIRIMSuruhanjaya TenagaBuatan MalaysiaMalaysia BrandIECEE CB SchemeRoHS

LED Cylindrical Surface Down Light (Elegance Series)

Use Cases :

Restaurant | Hotel | Retail | Office | Commercial | Shopping Mall

Wattage (W):

8W / 10W / 15W / 19W

Color Temperature (CCT):

2700 / 3000 / 4000 / 6500

Color Rendering Index (CRI):

85 / 95

Beam Angle:

15° / 25° / 40° / 60°

Lumen (lm):

760 / 1,100 / 1,400 / 1,800

Luminous Efficacy (lm/w):

95 / 92 / 93 / 95

Material:

Aluminium + Clear Glass Diffuser

Dimension (mm):

Ø: 100 x H: 155 / Ø: 120 x H: 200 / Ø: 140 x H: 180

Weight (gm):

780 / 880 / 900

Ingress Protection (IP):

IP20 / IP44

Lifespan (hrs):

50,000

Driver:

Internal - Non Dimming

Input Voltage:

220 - 240Vac (50/60 Hz)

Power Factor (PF):

> 0.90

Total Harmonic Distortion (THD):

< 20%

view more >

Specification

Part Number Wattage (W) CRI Lumen (lm) Dimension (mm) Lifespan (hrs) IP
LCSD315R▢-E08C▢▢▢ 8 85 / 95 760 Ø: 100 x H: 155 50,000 IP20 / IP44
LCSD315R▢-E12C▢▢▢ 12 85 / 95 1,100 Ø: 100 x H: 155 50,000 IP20 / IP44
LCSD315R▢-E15C▢▢▢ 15 85 / 95 1,400 Ø: 120 x H: 200 50,000 IP20 / IP44
LCSD315R▢-E19C▢▢▢ 19 85 / 95 1,800 Ø: 140 x H: 180 50,000 IP20 / IP44

Interested in this product?

Contact us for more information or request a free on-site consultation using the button below.
