LED Down Light Round
SIRIMSuruhanjaya TenagaBuatan MalaysiaMalaysia BrandIECEE CB SchemeRoHS

LED Down Light Round (Eco Elite Series)

Use Cases :

Retail | Office | Hospitality | Commercial | Residential

Wattage (W):

8W / 10W / 12W / 18W

Color Temperature (CCT):

3000 / 4000 / 6500

Color Rendering Index (CRI):

85

Beam Angle:

120°

Lumen (lm):

700 / 900 / 1,000 / 1,600

Luminous Efficacy (lm/w):

88 / 90 / 83 / 88

Material:

Aluminium + Polycarbonate (PC) Milky Diffuser

Dimension (mm):

Ø: 120 x H: 30 / Ø: 145 x H: 30 / Ø: 180 x H: 30 / Ø: 230 x H: 30

Cut Hole Size (mm):

90 / 110 / 135 / 190

Weight (gm):

165 / 192 / 274 / 426

Ingress Protection (IP):

IP20 / IP44

Lifespan (hrs):

35,000

Driver:

External - Non Dimming

Input Voltage:

220 - 240Vac (50/60 Hz)

Power Factor (PF):

> 0.90

Total Harmonic Distortion (THD):

< 12%

view more >

Specification

Part Number Wattage (W) CRI Lumen (lm) Dimension (mm) Lifespan (hrs) Cut Hole Size (mm)
LD3RES-A08E3P▢ 8 85 700 Ø: 120 x H: 30 35,000 90
LD4RES-A10E3P▢ 10 85 900 Ø: 145 x H: 30 35,000 110
LD6RES-A12E3P▢ 12 85 1,000 Ø: 180 x H: 30 35,000 135
LD6RES-A18E3P▢ 18 85 1,600 Ø: 180 x H: 30 35,000 135
LD8RES-A18E3P▢ 18 85 1,600 Ø: 230 x H: 30 35,000 190
