LED Deep Spot Down Light (Premium Plus Series)
Use Cases :
Airport | Retail | Office | Commercial | Shopping Mall
Wattage (W):
29W / 33W / 39W / 44W
Color Temperature (CCT):
2700 / 3000 / 4000 / 6500
Color Rendering Index (CRI):
85 / 95
Beam Angle:
160°
Lumen (lm):
3,500 / 3,700 / 4,000 / 4,250
Luminous Efficacy (lm/w):
121 / 112 / 103 / 97
Material:
Fully Aluminium Die Cast + Aluminium Reflector Polycarbonate (PC) Milky Diffuser
Dimension (mm):
Ø: 190 x H: 110 / Ø: 220 x H: 125
Cut Hole Size (mm):
170 / 200
Weight (gm):
675 / 1000
Ingress Protection (IP):
IP20 / IP44
Lifespan (hrs):
50,000
Driver:
External - Non Dimming / Dimming 1-10V, Phase Cut, DALI
Input Voltage:
220 - 240Vac (50/60 Hz)
Power Factor (PF):
0.95
Total Harmonic Distortion (THD):
< 20%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | Cut Hole Size (mm) |
|---|---|---|---|---|---|---|
| LS8RDP▢-A29E3PP▢ | 29 | 85 / 95 | 3,500 | Ø: 220 x H: 125 | 50,000 | 200 |
| L8RDP▢-A33E3PP▢ | 33 | 85 / 95 | 3,700 | Ø: 220 x H: 125 | 50,000 | 200 |
| LS8RDP▢-A39E3PP▢ | 39 | 85 / 95 | 4,000 | Ø: 220 x H: 125 | 50,000 | 200 |
| LS8RDP▢-A44E3PP▢ | 44 | 85 / 95 | 4,250 | Ø: 220 x H: 125 | 50,000 | 200 |
Interested in this product?
Contact us for more information or request a free on-site consultation using the button below.
