Indoor & Commercial > T8 LED Bare Channel
T8 LED Bare Channel (Eco Premium Plus Series)
Use Cases :
Retail | Office | Industrial | Hospitality
Wattage (W):
8W x 1 / 8W x 2 / 12W x 1 / 12W x 2 / 18W x 1 / 18W x 2
Colour Rendering Index (CRI):
> 80
Beam Angle:
160°
Lumen (lm):
1,360 / 2,720 / 2,100 / 4,200 / 3,000 / 6,000
Luminous Efficacy (lm/w):
170 / 175 / 168
Material:
Heavy Gauge Steel Sheet Body (Housing) + Polycarbonate (PC) Milky Diffuser with Built in Aluminium Heat Sink (TS LED Tube)
Dimension (mm):
L: 610 x W: 44 x H: 64 / L: 610 x W: 105 x H: 71 / L: 1220 x W: 44 x H: 64 / L: 1220 x W: 105 x H: 71 / L: 1220 x W: 44 x H: 64 / L: 1220 x W: 105 x H: 71
Weight (gm):
500 / 550 / 950 / 1000
Lamp Base:
G13
Ingress Protection (IP):
IP20
Lifespan (hrs):
60,000
Driver:
Internal - Non Dimming (Complied with JKR Spec)
Input Voltage:
220- 240Vac (50/60Hz)
Power Factor (PF):
> 0.95
Total Harmonic Distortion (THD):
< 11%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) |
|---|---|---|---|---|---|
| LBN58121E-P08ES3PM | 8W x 1 | > 80 | 1,360 | L: 610 x W: 44 x H: 64 | 60,000 |
| LBN58221E-P08ES3PM | 8W x 2 | > 80 | 2,720 | L: 610 x W: 105 x H: 71 | 60,000 |
| LBN58141E-P12ES3PM | 12W x 1 | > 80 | 2,100 | L: 1220 x W: 44 x H: 64 | 60,000 |
| LBN58241E-P12ES3PM | 12W x 2 | > 80 | 4,200 | L: 1220 x W: 105 x H: 71 | 60,000 |
| LBN58141E-P18ES3PM | 18W x 1 | > 80 | 3,000 | L: 1220 x W: 44 x H: 64 | 60,000 |
| LBN58241E-P18ES3PM | 18W x 2 | > 80 | 6,000 | L: 1220 x W: 105 x H: 71 | 60,000 |
