Wattage (W):

80W / 100W /120W / 150W

Colour Rendering Index (CRI):

> 70

Beam Angle:

120°

Lumen (lm):

14,400 / 18,000 / 21,600 / 27,000

Luminous Efficacy (lm/w):

180

Solar Panel Type:

High Efficiency Monocrystalline Silicon

Maximum Power (W):

36V 240W / 36V 350W

Solar Lifespan:

25 Years

Material:

Aluminium Alloy + Galvanized Iron + Polycarbonate (PC) Lens

Dimension (mm) :

L: 1760 x W: 705 x H: 96 / L: 1980 x W: 905 x H: 125

Weight (kg):

55.0kg / 77.0kg / 87.0kg

Pole Bracket Weight (kg):

Inner Diameter: 92mm (6.8kg) / 145mm (7.2kg)

Ingress Protection (IP):

IP66

Lifespan (hrs):

60,000

Battery Type:

Lithium Iron Phosphate (LiFePO4) Battery

Battery Capacity :

25.6V 126AH / 25.6V 156AH / 25.6V 210AH / 25.6V 264AH

System Controller:

12hrs: 100%

Discharge Time:

12 Hours ( Autonomy ≥ 3 Cloudy / Rainy Days )

Charge Time:

4.5 – 6 Hours

Pole Height (m):

6 – 8m / 8 – 10m / 10 – 12m

Pole Spigot Diameter (ø: mm):

89mm (Galvanized Pole) / 140mm (Concrete Pole)

Optional Smart Solar Controller:

4-Pin RS485 MPPT Connector: Support LEMS, LORA, NB-IoT Smart Lighting System (Optional)
