Outdoor Lighting > LED Sport Stadium Light
LED Sport Stadium Light (MaxPro Series)
Use Cases :
Industrial | Outdoor | Highway | Compound
Wattage (W):
500W / 600W / 1000W / 1200W / 1500W / 1800W / 2000W / 2400W
Colour Rendering Index (CRI):
> 70
Beam Angle:
15° / 30° / 60° / 90° / 120° / Asymmetrical
Lumen (lm):
90,000 / 108,000 / 180,000 / 216,000 / 270,000 / 324,000 / 360,000 / 432,000
Luminous Efficacy (lm/w):
180
Material:
Pure Aluminium Die Cast with Clear Tempered Glass Diffuser (Option: Anti-Glare Reflector)
Dimension (mm):
L: 540 x W: 285 x H: 200 / L: 540 x W: 590 x H: 200 / L: 540 x W: 895 x H: 200 / L: 540 x W: 1200 x H: 200
Weight (gm):
14,000 / 28,500 / 43,000 / 56,500
Ingress Protection (IP):
IP66
Impact Resistance Glass:
IK08
Lifespan (hrs):
60,000
Driver:
External - Non Dimming / Dimming + Surge Protection Device (SPD)
Input Voltage:
100 - 240 Vac (50/60 Hz)
Power Factor (PF):
> 0.95
Total Harmonic Distortion (THD):
< 12%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) |
|---|---|---|---|---|---|
| LHML-A500PN5G | 500W | > 70 | 90,000 | L: 540 x W: 285 x H: 200 | 60,000 |
| LHML-A600PN5G | 600W | > 70 | 108,000 | L: 540 x W: 285 x H: 200 | 60,000 |
| LHML-A1000PN5G | 1000W | > 70 | 180,000 | L: 540 x W: 590 x H: 200 | 60,000 |
| LHML-A1200PN5G | 1200W | > 70 | 216,000 | L: 540 x W: 590 x H: 200 | 60,000 |
| LHML-A1500PN5G | 1500W | > 70 | 270,000 | L: 540 x W: 895 x H: 200 | 60,000 |
| LHML-A1800PN5G | 1800W | > 70 | 324,000 | L: 540 x W: 895 x H: 200 | 60,000 |
| LHML-A2000PN5G | 2000W | > 70 | 360,000 | L: 540 x W: 1200 x H: 200 | 60,000 |
| LHML-A2400PN5G | 2400W | > 70 | 432,000 | L: 540 x W: 1200 x H: 200 | 60,000 |
Interested in this product?
Contact us for more information or request a free on-site consultation using the button below.
