LED Backlit Panel Light-bak (Premiere Series)
Use Cases :
Retail | Office | Industrial | Hospitality
Wattage (W):
20W / 25W / 30W / 40W / 60W / 80W
Colour Rendering Index (CRI):
> 85
Beam Angle:
120°
Lumen (lm):
2,700 / 3,375 / 4,050 / 5,400 / 8,100 / 10,800
Luminous Efficacy (lm/w):
135
Material:
Aluminium Panel with Anti-Glare Polycarbonate (PC) Milky Diffuser
Dimension (mm):
L: 595 x W: 595 x H: 30 / L: 1195 x W: 295 x H: 30 / L: 1195 x W: 595 x H: 30
Housing Thickness (mm):
0.6mm
Weight (kg):
2.30kg / 3.30kg / 4.10kg
Ingress Protection (IP):
IP20 / IP40
Lifespan (hrs):
60,000
Driver:
External – Non Dimming / Dimming 1 - 10V, Phase Cut, DALI
Input Voltage:
220 - 240Vac (50/60 Hz)
Power Factor (PF):
> 0.95
Total Harmonic Distortion (THD):
< 15%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) |
|---|---|---|---|---|---|
| LBP606☐-A20PN3P☐ | 20W | > 85 | 2,700 | L: 595mm x W: 595mm x H: 30mm | 60,000 |
| LBP606☐-A25PN3P☐ | 25W | > 85 | 3,375 | L: 595mm x W: 595mm x H: 30mm | 60,000 |
| LBP606☐-A30PN3P☐ | 30W | > 85 | 4,050 | L: 595mm x W: 595mm x H: 30mm | 60,000 |
| LBP606☐-A40PN3P☐ | 40W | > 85 | 5,000 | L: 595mm x W: 595mm x H: 30mm | 60,000 |
| LBP312☐-A40PN3P☐ | 40W | > 85 | 5,400 | L: 1195mm x W: 295mm x H: 30mm | 60,000 |
| LBP612☐-A60PN3P☐ | 60W | > 85 | 8,100 | L: 1195mm x W: 595mm x H: 30mm | 60,000 |
| LBP612☐-A80PN3P☐ | 80W | > 85 | 10,800 | L: 1195mm x W: 595mm x H: 30mm | 60,000 |
