Outdoor Lighting > LED Bulk Head Light

LED Bulk Head Light (Eco Elegant Series)

Use Cases :

Wattage (W):

12W / 18W / 20W / 30W

Color Temperature (CCT):

2700 / 3000 / 4000 / 5000

Color Rendering Index (CRI):

Beam Angle:

120°

Lumen (lm):

1,200 / 1,800 / 2,000 / 3,000

Luminous Efficacy (lm/w):

100 / 100 / 100 / 100

Material:

Aluminium Die Cast +Polycarbonate (PC) Diffuser

Dimension (mm):

Ø: 145 x H: 65 / Ø: 230 x H: 80 / Ø: 280 x H: 90 / Ø: 360 x H: 130

Weight (gm):

800 / 1000 / 1200 / 1500

Ingress Protection (IP):

IP65

Lifespan (hrs):

50,000

Driver:

Internal - Non Dimming / Dimming 1-10V, Phase Cut, DALI

Input Voltage:

220 - 240Vac (50/60 Hz)

Power Factor (PF):

> 0.90

Total Harmonic Distortion (THD):

< 12%

Specification

Part Number	Wattage (W)	CRI	Lumen (lm)	Dimension (mm)	Lifespan (hrs)	IP
LBH6R▢-A12E3P▢	12	85	1,200	Ø: 145 x H: 65	50,000	IP65
LBH8R▢-A18E3P▢	18	85	1,800	Ø: 230 x H: 80	50,000	IP65
LBH12R▢-A20E3P▢	20	85	2,000	Ø: 280 x H: 90	50,000	IP65
LBH14R▢-A30E3P▢	30	85	3,000	Ø: 360 x H: 130	50,000	IP65
