Indoor & Commercial Bak > LED Down Light Square-bak
LED Down Light Square-bak (Eco Premiere Series)
Use Cases :
Retail | Office | Commercial | Shopping Mall | Residential
Wattage (W):
15W / 19W
Colour Rendering Index (CRI):
85
Beam Angle:
120°
Lumen (lm):
2,100 / 2,800
Luminous Efficacy (lm/w):
140 / 147
Material:
Fully Aluminium + Polycarbonate (PC) Milky Diffuser
Dimension L x W x H (mm) :
140 x 140 x 60 / 180 x 180 x 70 / 220 x 220 x 70
Cut Hole Size (mm):
120 x 120 / 150 x 150 / 200 x 200
Weight (gm):
380 / 650 / 800
Ingress Protection (IP):
IP20 / IP44
Lifespan (hrs):
60,000
Driver:
External – Non Dimming / Dimming - 1 - 10V, Phase Cut, DALI
Input Voltage:
220 - 240Vac (50/60 Hz)
Power Factor (PF):
> 0.95
Total Harmonic Distortion (THD):
< 12%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) |
|---|---|---|---|---|---|
| LD4SC-A15PE3P☐ | 15W | 85 | 2,100 | L: 140mm x W: 140mm x H: 60mm | 60,000 |
| LD6SC-A15PE3P☐ | 15W | 85 | 2,100 | L: 180mm x W: 180mm x H: 70mm | 60,000 |
| LD6SC-A19PE3P☐ | 19W | 85 | 2,800 | L: 180mm x W: 180mm x H: 70mm | 60,000 |
| LD8SC-A15PE3P☐ | 15W | 85 | 2,100 | L: 220mm x W: 220mm x H: 70mm | 60,000 |
| LD8SC-A19PE3P☐ | 19W | 85 | 2,800 | L: 220mm x W: 220mm x H: 70mm | 60,000 |
