Industrial Lighting > LED Low & High Bay
LED Low & High Bay (Eco Premium Series)
Use Cases :
Industrial | Architectural | Shopping Mall | Warehouse | Supermarket
Wattage (W):
80W / 100W / 140W / 180W / 200W
Color Temperature (CCT):
3000 / 4000 / 5000
Color Rendering Index (CRI):
85
Beam Angle:
120°
Lumen (lm):
11,000 / 13,500 / 19,000 / 24,500 / 27,000
Luminous Efficacy (lm/w):
138 / 135 / 136 / 136 / 135
Material:
Aluminium Die Cast + Clear Glass Diffuser (Option: Reflector)
Dimension (mm):
Ø: 280 x H: 210 / Ø: 325 x H: 225
Weight (gm):
2000 / 4000 / 4500
Lamp Base:
Hook Type
Ingress Protection (IP):
IP65
Lifespan (hrs):
50,000
Driver:
External - Non Dimming / Dimming 1-10V
Input Voltage:
100 - 240Vac (50/60 Hz)
Power Factor (PF):
0.95
Total Harmonic Distortion (THD):
< 15%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | IP |
|---|---|---|---|---|---|---|
| LLBCP-A080N3G▢ | 80 | 85 | 11,000 | Ø: 280 x H: 210 | 50,000 | IP65 |
| LLBCP-A100N3G▢ | 100 | 85 | 13,500 | Ø: 280 x H: 210 | 50,000 | IP65 |
| LLBCP-A140N3G▢ | 140 | 85 | 19,000 | Ø: 325 x H: 225 | 50,000 | IP65 |
| LLBCP-A180N3G▢ | 180 | 85 | 24,500 | Ø: 325 x H: 225 | 50,000 | IP65 |
| LLBCP-A200N3G▢ | 200 | 85 | 27,000 | Ø: 325 x H: 225 | 50,000 | IP65 |
