Facade Lighting > LED Surface Wall Downlight
LED Surface Wall Downlight (Elegant Series)
Use Cases :
Architectural | Commercial | Outdoor | Facade
Wattage (W):
5W / 12W / 18W / 30W
Color Temperature (CCT):
1800 / 2200 / 2700 / 3000 / 4000 / 5000
Color Rendering Index (CRI):
85 / 95
Beam Angle:
40° / 60°
Lumen (lm):
350 / 850 / 1,300 / 2,300
Luminous Efficacy (lm/w):
70 / 71 / 72 / 77
Material:
Aluminium Die Cast + Tempered Glass Diffuser
Dimension (mm):
Ø: 65 x H: 120 / Ø: 100 x H: 150 / Ø: 90 x H: 200 / Ø: 120 x H: 200 / Ø: 150 x H: 230
Weight (gm):
560 / 650 / 886 / 900
Ingress Protection (IP):
IP65
Lifespan (hrs):
50,000
Driver:
Internal - Non Dimming
Input Voltage:
220 - 240Vac (50/60 Hz)
Power Factor (PF):
0.95
Total Harmonic Distortion (THD):
< 12%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | IP |
|---|---|---|---|---|---|---|
| LSWLD1RS-A05C▢▢▢ | 5 | 85 / 95 | 350 | Ø: 65 x H: 120 | 50,000 | IP65 |
| LSWLD2RS-A12C▢▢▢ | 12 | 85 / 95 | 850 | Ø: 100 x H: 150 | 50,000 | IP65 |
| LSWLD3RS-A12C▢▢▢ | 12 | 85 / 95 | 850 | Ø: 90 x H: 200 | 50,000 | IP65 |
| LSWLD4RS-A18C▢▢▢ | 18 | 85 / 95 | 1,300 | Ø: 120 x H: 200 | 50,000 | IP65 |
| LSWLD4RS-A30C▢▢▢ | 30 | 85 / 95 | 2,300 | Ø: 150 x H: 230 | 50,000 | IP65 |
Interested in this product?
Contact us for more information or request a free on-site consultation using the button below.
