Indoor & Commercial > T8 LED Bare Channel
T8 LED Bare Channel (Eco Elite Master Series)
Use Cases :
Retail | Office | Industrial | Hospitality
Wattage (W):
8W x 1 / 8W x 2 / 16W x 1 / 16W x 2 / 18W x 1 / 18W x 2
Colour Rendering Index (CRI):
> 80
Beam Angle:
160°
Lumen (lm):
1,050 / 2,100 / 4,200 / 2,300 / 4,600
Luminous Efficacy (lm/w):
131 / 128
Material:
Heavy Gauge Steel Sheet Body (Housing) + Polycarbonate (PC) Milky Diffuser (T8 LED Tube)
Dimension (mm):
L: 610 x W: 44 x H: 64 / L: 610 x W: 105 x H: 71 / L: 1220 x W: 44 x H: 64 / L: 1220 x W: 105 x H: 71
Weight (gm):
500 / 550 / 950 / 1,000
Lamp Base:
G13
Ingress Protection (IP):
IP20
Lifespan (hrs):
50,000
Driver:
Internal - Non Dimming (Complied with JKR Spec)
Input Voltage:
220 - 240Vac (50/ 60 Hz)
Power Factor (PF):
> 0.95
Total Harmonic Distortion (THD):
< 11%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) |
|---|---|---|---|---|---|
| LBN58121E-P08ES3EM | 8W x 1 | > 80 | 1,050 | L: 610 x W: 44 x H: 64 | 50,000 |
| LBN58221E-P08ES3EM | 8W x 2 | > 80 | 2,100 | L: 610 x W: 105 x H: 71 | 50,000 |
| LBN58141EP-16ES3EM | 16W x 1 | > 80 | 2,100 | L: 1220 x W: 44 x H: 64 | 50,000 |
| LBN58241E-P16ES3EM | 16W x 2 | > 80 | 4,200 | L: 1220 x W: 105 x H: 71 | 50,000 |
| LBN58141E-P18ES3EM | 18W x 1 | > 80 | 2,300 | L: 1220 x W: 44 x H: 64 | 50,000 |
| LBN58241E-P18ES3EM | 18W x 2 | > 80 | 4,600 | L: 1220 x W: 105 x H: 71 | 50,000 |
Interested in this product?
Contact us for more information or request a free on-site consultation using the button below.
