Indoor & Commercial > T8 LED Tube
T8 LED Tube (Eco Master Series)
Use Cases :
Restaurant | Retail | Office | Industrial | Hospitality | Carpark
Wattage (W):
9W / 12W / 16W / 20W
Color Temperature (CCT):
3000 / 4000 / 5000 / 6500
Colour Rendering Index (CRI):
85
Beam Angle:
160°
Lumen (lm):
1,300 / 1,800 / 2,300 / 2,900
Luminous Efficacy (lm/w):
145 / 150 / 144 / 145
Material:
Polycarbonate (PC) Milky Diffuser (Option: Clear Diffuser)
Dimension (mm):
Ø: 26 x L: 600 / Ø: 26 x L: 1200 / Ø: 26 x L: 1500
Weight (gm):
117 / 206 / 246
Lamp Base :
G13
Ingress Protection (IP) :
IP20
Lifespan (hrs):
50,000
Driver:
Internal - Non Dimming (Comply with JKR Spec)
Input Voltage:
220 - 240Vac (50/60 Hz)
Power Factor (PF):
> 0.90
Total Harmonic Distortion (THD):
< 12%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | Supply |
|---|---|---|---|---|---|---|
| LTV2S-P09ES3M▢ | 9 | 85 | 1,300 | Ø: 26 x L: 600 | 50,000 | 1E |
| LTV2S-P09E3M▢ | 9 | 85 | 1,300 | Ø: 26 x L: 600 | 50,000 | 2E |
| LTV8-P12ES3M▢ | 12 | 85 | 1,800 | Ø: 26 x L: 1200 | 50,000 | 1E |
| LTV8-P12E3M▢ | 12 | 85 | 1,800 | Ø: 26 x L: 1200 | 50,000 | 2E |
| LTV8-P16ES3M▢ | 16 | 85 | 2,300 | Ø: 26 x L: 1200 | 50,000 | 1E |
| LTV8-P16E3M▢ | 16 | 85 | 2,300 | Ø: 26 x L: 1200 | 50,000 | 2E |
| LTV8-P20ES3M▢ | 20 | 85 | 2,900 | Ø: 26 x L: 1500 | 50,000 | 1E |
| LTV8-P20E3M▢ | 20 | 85 | 2,900 | Ø: 26 x L: 1500 | 50,000 | 2E |
Interested in this product?
Contact us for more information or request a free on-site consultation using the button below.
