T8 LED Tube (Eco Premium Plus Series)
Use Cases :
Retail | Office | Industrial | Hospitality
Wattage (W):
9W / 9.5W / 12W / 16W
Color Temperature (CCT):
3000 / 4000 / 5000 / 6500
Color Rendering Index (CRI):
85
Beam Angle :
160°
Lumen (lm):
1,400 / 1,600 / 2,100 / 2,650
Luminous Efficacy (lm/w):
155 / 168 / 173 / 166
Material:
Polycarbonate (PC) Milky Diffuser (Option: Clear Diffuser)
Dimension (mm):
Ø: 26 x L: 600 / Ø: 26 x L: 1200
Weight (gm):
120 / 210
Lamp Base:
G13
Ingress Protection:
IP20
Lifespan (hrs):
60,000
Driver:
Internal - Non Dimming (Comply with JKR Spec)
Input Voltage:
220 - 240Vac (50/60 Hz)
Power Factor (PF):
> 0.90
Total Harmonic Distortion (THD):
< 12%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | Supply |
|---|---|---|---|---|---|---|
| LTV2S-P09ES3PM▢ | 9 | 85 | 1,400 | Ø: 26 x L: 600 | 60,000 | 1E |
| LTV2S-P09E3PM▢ | 9 | 85 | 1,400 | Ø: 26 x L: 600 | 60,000 | 2E |
| LTV8-P09ES3PM▢ | 9.5 | 85 | 1,600 | Ø: 26 x L: 1200 | 60,000 | 1E |
| LTV8-P09E3PM▢ | 9.5 | 85 | 1,600 | Ø: 26 x L: 1200 | 60,000 | 2E |
| LTV8-P12ES3PM▢ | 12 | 85 | 2,100 | Ø: 26 x L: 1200 | 60,000 | 1E |
| LTV8-P12E3PM▢ | 12 | 85 | 2,100 | Ø: 26 x L: 1200 | 60,000 | 2E |
| LTV8-P16ES3PM▢ | 16 | 85 | 2,650 | Ø: 26 x L: 1200 | 60,000 | 1E |
| LTV8-P16E3PM▢ | 166 | 85 | 2,650 | Ø: 26 x L: 1200 | 60,000 | 2E |
