Facade Lighting > LED Inground Drive Over Light (Eco Elegant Series)
LED Inground Drive Over Light (Eco Elegant Series)
Use Cases :
Driveway | Parking Lot | Pathway | Landscape | Inground Drive-Over | Architectural | Commercial Area
Wattage (W):
2W / 5W / 12W
Color Temperature (CCT):
2700K / 3000K / 4000K / 5000K
Color Rendering Index (CRI):
85 / 95
Beam Angle:
15° / 25°
Lumen (lm):
80 / 200 / 500
Luminous Efficacy (lm/w):
40 / 40 / 46
Material:
Aluminium Die Cast + Stainless Steel + Tempered Glass Diffuser + ABS Mounting Sleeve Kit
Dimension (mm):
Ø: 42 x H: 72 / Ø: 62 x H: 72 / Ø: 110 x H: 135
Cut Hole Size (mm):
Ø: 38 x H: 72 / Ø: 55 x H: 86 / Ø: 100 x H: 135
Weight (gm):
153 / 266 / 1,004
Ingress Protection (IP):
IP65 / IP67
Lifespan (hrs):
50,000
Driver:
External - 24V Non Dimming / Dimming 1-10V / Internal - Non Dimming
Driver Part Number:
LOMW24V-□□W
Input Voltage:
24 Vdc
Power Factor (PF):
> 0.95
Driver Ingress Protection (IP):
IP67
Total Harmonic Distortion (THD):
-
Specification
| Part Number | Wattage (W) | CCT (K) | CRI | Lumen (lm) | Dimension (mm) | Weight (gm) | IP Rating |
|---|---|---|---|---|---|---|---|
| LS-IGD-ELEG-2W | 2 | 2700/3000/4000/5000 | 85/95 | 80 | Ø42 x H72 | 153 | IP65 / IP67 |
| LS-IGD-ELEG-5W | 5 | 2700/3000/4000/5000 | 85/95 | 200 | Ø62 x H72 | 266 | IP65 / IP67 |
| LS-IGD-ELEG-12W | 12 | 2700/3000/4000/5000 | 85/95 | 500 | Ø110 x H135 | 1,004 | IP65 / IP67 |
Interested in this product?
Contact us for more information or request a free on-site consultation using the button below.
