Indoor & Commercial > LED Down Light Round
LED Down Light Round (Eco Premiere Series)
Use Cases :
Hospital | Retail | Commercial | Shopping Mall | Indoor
Wattage (W):
15W / 19W / 26W / 29W
Color Rendering Index (CRI):
> 85
Beam Angle:
120°
Lumen (lm):
2,100 / 2,800 / 3,800 / 4,200
Luminous Efficacy (lm/w):
140 / 145 / 146 / 147
Material:
Fully Aluminium + Polycarbonate (PC) Milky Diffuser
Dimension (mm):
Ø: 175 x H: 55 / Ø: 240 x H: 78
Cut Hole Size (mm):
150 / 200
Weight (gm):
275 / 580
Ingress Protection (IP):
IP20 / IP44
Lifespan (hrs):
60,000
Driver:
External - Non Dimming / Dimming 1-10V, Phase Cut, DALI
Input Voltage:
220 - 240Vac (50/60 Hz)
Power Factor (PF):
> 0.95
Total Harmonic Distortion (THD):
< 15%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | Cut Hole Size (mm) |
|---|---|---|---|---|---|---|
| LD6RC-A15B▢E3P▢ | 15W | > 85 | 2,100 | Ø: 175 x H: 55 mm | 60,000 | 150 |
| LD6RC-A19B▢E3P▢ | 19W | > 85 | 2,800 | Ø: 175 x H: 55 mm | 60,000 | 150 |
| LD8RC-A15B▢E3P▢ | 15W | > 85 | 2,100 | Ø: 240 x H: 78 mm | 60,000 | 200 |
| LD8RC-A19B▢E3P▢ | 19W | > 85 | 2,800 | Ø: 240 x H: 78 | 60,000 | 200 |
| LD8RC-A26▢E3PP▢ | 26W | > 85 | 3,800 | Ø: 240 x H: 78 mm | 60,000 | 200 |
| LD8RC-A29▢E3PP▢ | 29W | > 85 | 4,200 | Ø: 240 x H: 78 mm | 60,000 | 200 |
