Outdoor Lighting > LED Smart Street Light

LED Smart Street Light (Eco Premium Series)

Use Cases :

Industrial | Outdoor | Highway | Compound

Wattage (W):

120W / 150W / 180W / 200W / 240W

Color Rendering Index (CRI):

> 70

Beam Angle:

120°

Lumen (lm):

20,400 / 25,500 / 30,600 / 34,000 /40,800

Luminous Efficacy (lm/w):

170

Material:

Pure Aluminium Die Cast with Clear Tempered Glass Diffuser

Dimension (mm):

L: 780 x W:300 x H: 155

Weight (gm):

8,000

Ingress Protection (IP):

IP66

Impact Resistance Glass:

IK08

Lifespan (hrs):

60,000

Driver:

Internal - Non Dimming / Dimming + Surge Protection Device (SPD)

Input Voltage:

100 - 240Vac (50/60 Hz)

Power Factor (PF):

> 0.95

Total Harmonic Distortion (THD):

< 11%

NEMA Socket:

7-Pin NEMA ANSI Connector : Support LEMS, LORA, NB-IOT Smart Lighting System (Optional)

view less >

Specification

Part Number	Wattage (W)	CRI	Lumen (lm)	Dimension (mm)	Lifespan (hrs)	Ingress Protection (IP)
LSTLCP-A120N5G	120W	> 70	20,400	L: 780 x W:300 x H: 155	60,000	IP66
LSTLCP-A150N5G	150W	> 70	25,500	L: 780 x W:300 x H: 155	60,000	IP66
LSTLCP-A180N5G	180W	> 70	30,600	L: 780 x W:300 x H: 155	60,000	IP66
LSTLCP-A200N5G	200W	> 70	34,000	L: 780 x W:300 x H: 155	60,000	IP66
LSTLCP-A240N5G	240W	> 70	40,800	L: 780 x W:300 x H: 155	60,000	IP66
