Wattage (W):

60W / 80W / 100W / 120W / 150W / 200W

ColourRendering Index (CRI):

> 70

Beam Angle:

15° / 30° / 60° / 90° / 120°

Lumen (lm):

9,600 / 12,800 / 16,500 / 19,800 / 24,750 / 33,000

Luminous Efficacy (lm/w):

160 / 165

Light Material:

Aluminium Die Cast with Tempered Glass Diffuser

Light Dimension (mm):

L: 340 x W: 270 x H: 52 / L: 395 x W: 395 x H: 56 / L: 500 x W: 395 x H: 56

Light Weight (kg):

3.3kg / 4.5kg / 6.6kg

Ingress Protection (IP):

IP66

Impact Resistance Glass:

IK08

Lifespan (hrs):

60,000

Solar Panel Type:

High Efficiency Monocrystalline Silicon

Maximum Power:

18V 120W / 36V 160W / 36V 200W / 36v 240W

Integrated Compartment (mm):

L: 1342 x W: 488 x H: 96 / L: 1235x W: 705 x H: 96 / L: 1480 W: 705 H: 96 / L: 1760 x H: 705 x W: 96

Solar Lifespan:

25 years

Integrated Compartment Weight (kg) :

32.0kg / 34.0kg / 35.5kg / 38.5kg / 43.0kg / 52.5kg

Battery Type:

LiFeP04 Lithium Battery

Battery Capacity:

12.8V 72AH / 12.8V 96AH / 12.8V 108AH / 25.6V 60AH / 25.6V 78AH / 25.6V 120AH

System Controller:

Time Control (4hrs: 100%, 2hrs: 60%, 6hrs: 40%) / Microwave Sensor

Discharge Time:

12 Hours ( Autonomy ≤2 Cloudy / Rainy Days )

Charge Time:

4.5 -6 hours (Strong Sunlight)

Operation Temperature (°C):

20°C to +65°C

Mounting Height (m):

4 – 7m / 5 – 8m / 5 – 9m / 8 – 10m / 10 – 12m

Pole Spigot Diameter (Ø: mm):

65 / 89mm (Galvanized Pole) / 140mm (Concrete Pole)

Optional Smart Solar Controller:

4-Pin RS485 MPPT Connector: Support LEMS, LORA, NB-IoT Smart Lighting System (Optional)
