Facade Lighting > LED Flexible Silicone Strip Square
LED Flexible Silicone Strip Square (Elegant Series)
Use Cases :
Architectural | Commercial | Outdoor | Facade
Wattage (W):
10W / M / 12W / M / 15W / M / 18W /M / 20W / M
Color Temperature (CCT):
RGB
Color Rendering Index (CRI):
85 / 95
Beam Angle:
120°
Lumen (lm):
400 / 940 / 1,080 / 1,560 / 1,800
Luminous Efficacy (lm/w):
40 / 78 / 72 / 87 / 82
Material:
Silicon White + Milky Diffuser
Dimension (mm):
L: 1000 x W: 16 x H:16
Weight (gm):
210 / 240 / 260
Ingress Protection (IP):
IP65
Lifespan (hrs):
30,000 / 50,000 / 60,000
Driver:
External - 24V Non Dimming / Dimming 1-10V, DALI
Driver Part Number:
LMW24V-▢▢W / LOMW24V-▢▢W
Input Voltage:
24 Vdc
Driver Ingress Protection (IP):
IP20 / IP67
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | Driver Part Number |
|---|---|---|---|---|---|---|
| LFS121224E-S08C3M▢ | 8W/M | 85 / 95 | 320 | L: 1000 x W: 12 x H:12 | 30,000 / 50,000 / 60,000 | LMW24V-▢▢W |
| LFS151524E-S12C3M▢ | 12W/M | 85 / 95 | 480 | L: 1000 x W: 15 x H:15 | 30,000 / 50,000 / 60,000 | LOMW24V-▢▢W |
| LFS161624E-S10C3M▢ | 10W / M | 85 / 95 | 400 | L: 1000 x W: 16 x H:16 | 30,000 / 50,000 / 60,000 | LMW24V-▢▢W |
| LFS161624E-S12C3M▢ | 12W / M | 85 / 95 | 940 | L: 1000 x W: 16 x H:16 | 30,000 / 50,000 / 60,000 | LMW24V-▢▢W |
| LFS161624E-S15C3M▢ | 15W / M | 85 / 95 | 1,080 | L: 1000 x W: 16 x H:16 | 30,000 / 50,000 / 60,000 | LMW24V-▢▢W |
| LFS161624E-S18C3M▢ | 18W / M | 85 / 95 | 1,560 | L: 1000 x W: 16 x H:16 | 30,000 / 50,000 / 60,000 | LOMW24V-▢▢W |
| LFS161624E-S22C3M▢ | 22 | 85 / 95 | 1,800 | L: 1000 x W: 16 x H:16 | 30,000 / 50,000 / 60,000 | LOMW24V-▢▢W |
