Wattage (W):

60W / 80W / 100W / 120W / 150W

Colour Rendering Index (CRI):

> 70

Beam Angle:

120°

Lumen (lm):

10,800 / 14,400 / 18,000 / 21,600 / 27,000

Luminous Efficacy (lm/w):

180

Solar Panel Type:

High Efficiency Monocrystalline Silicon

Solar Power (W):

36V 160W / 36V 200W / 36V 240W / 36V 300W

Material :

Aluminium Alloy + Galvanized Iron + Polycarbonate (PC) Lens

Dimension (mm):

L: 1235 x W: 705 x H: 96 / L: 1480 x W: 705 x H: 96 / L: 1760 x W: 705 x H: 96 / L: 1640 x W: 905 x H: 125

Weight (kg):

37.5kg / 38.0kg / 38.5kg / 45.0kg / 47.0kg / 51.0kg / 57.0kg

Pole Bracket Weight:

ID (80mm) : 6.5kg / ID (92mm) : 7.2kg

Ingress Protection (IP):

IP66

Lifespan (hrs):

60,000

Battery Type:

Lithium Iron Phosphate (LiFePO4) Battery

Battery Capacity:

25.6V 60AH / 25.6V 90AH / 25.6V 114AH

System Controller:

Time Control (4hrs : 100%, 2 Hrs : 60%, 6 hrs 40%)

Discharge Time:

> 2 Cloudy / Rainy Days

Charge TIme:

4 - 6 hours

Operating Temperature:

-20°C to +65°C

Pole Height (m):

5 - 8m / 6 - 8m / 8 - 10m / 10 - 12m /

Pole Spigot Diameter (Ø: mm):

76 / 89mm ( Galvanized Pole) / 140mm (Concrete Pole)
