Outdoor Lighting > LED Flood Light
LED Flood Light (Eco Premium Series)
Use Cases :
Industrial | Outdoor | Highway | Compound
Wattage (W):
100W / 120W / 150W / 180W / 200W / 250W / 300W / 400W / 450W
Color Rendering Index (CRI):
> 70
Beam Angle:
15° / 30° / 60° / 90° / 120° / Asymmetrical
Lumen (lm):
16,500 / 19,800 / 24,750 / 29,700 / 33,000 / 41,250 / 49,500 / 66,000 / 74,250
Luminous Efficacy (lm/w):
165
Material:
Aluminum Die Cast with Tempered Glass Diffuser
Dimension (mm):
L: 395 x W: 395 x H56 / L: 500 x W: 395 x H: 56 / L: 510 x W: 550 x H: 65
Weight (gm):
4,500 / 6,600 / 6,800 / 9,300 /10,500
Ingress Protection (IP):
IP66
Impact Resistance Glass:
IK08
Lifespan (hrs):
60,000
Driver:
Internal - Non Dimming / Dimming + Durge Protection Device (SPD)
Input Voltage:
100 - 240Vac (50 / 60 Hz)
Power Factor:
> 0.95
Total Harmonic Distortion (THD):
< 12%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) |
|---|---|---|---|---|---|
| LFL-A100PN5G | 100W | > 70 | 16,500 | L: 395 x W: 395 x H56 | 60,000 |
| LFL-A100PN5G | 120W | > 70 | 19,800 | L: 395 x W: 395 x H56 | 60,000 |
| LFL-A150PN5G | 150W | > 70 | 24,750 | L: 395 x W: 395 x H56 | 60,000 |
| LFL-A180PN5G | 180W | > 70 | 29,700 | L: 500 x W: 395 x H56 | 60,000 |
| LFL-A200PN5G | 200W | > 70 | 33,000 | L: 500 x W: 395 x H56 | 60,000 |
| LFL-A250PN5G | 250W | > 70 | 41,250 | L: 500 x W: 395 x H56 | 60,000 |
| LFL-A300PN5G | 300W | > 70 | 49,500 | L: 510 x W: 550 x H56 | 60,000 |
| LFL-A400PN5G | 400W | > 70 | 66,000 | L: 510 x W: 550 x H56 | 60,000 |
| LFL-A450PN5G | 450W | > 70 | 74,250 | L: 510 x W: 550 x H56 | 60,000 |
Interested in this product?
Contact us for more information or request a free on-site consultation using the button below.
