Indoor & Commercial > LED Modular Panel Light
LED Modular Panel Light (Premiere Series)
Use Cases :
Retail | Office | Industrial | Hospitality
Wattage (W):
40W / 50W
Color Temperature (CCT):
3000 / 4000 / 6500
Color Rendering Index (CRI):
85
Beam Angle:
120°
Lumen (lm):
4,500 / 5,500
Luminous Efficacy (lm/w):
113 / 110
Material:
Modular Aluminium Panel + Polycarbonate (PC) Milky Diffuser
Dimension (mm):
L: 1200 x W: 300 x H: 65 / L: 1200 x W: 600 x H: 65
Weight (gm):
6000 / 8000
Ingress Protection (IP):
IP44
Lifespan (hrs):
50,000
Driver:
External - Non Dimming / Dimming 1-10V, Phase Cut, DALI
Input Voltage:
220 - 240Vac (50/60 Hz)
Power Factor (PF):
> 0.90
Total Harmonic Distortion (THD):
< 20%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | IP |
|---|---|---|---|---|---|---|
| LMP312▢-A40E3PM▢ | 40 | 85 | 4,500 | L: 1200 x W: 300 x H: 65 | 50,000 | IP44 |
| LMP612▢-A50E3PM▢ | 50 | 85 | 5,500 | L: 1200 x W: 600 x H: 65 | 50,000 | IP44 |
