Outdoor Lighting > LED Solar Linear Batten
Use Cases :
Industrial | Outdoor | Highway | Compound
Wattage:
18W / 21W
Color Rendering Index (CRI):
> 80
Beam Angle:
120°
Lumen (lm):
2,350 / 2,750
Luminous Efficacy (lm/w):
131
Light Material:
Solid Fully Polycarbonate (PC) + Milky Diffuser
Light Dimension (mm):
L: 600 x W: 80 x H: 77
Light Weight (gm):
700
Ingress Protection (IP):
IP65
Lifespan (hrs):
60,000
Solar Panel Type:
High Efficiency Monocrystalline Silicon
Maximum Power:
18V 50W
Solar Panel Dimension (mm):
L: 670 x W: 400
Solar Lifespan:
25 years
Compartment Type:
Polycarbonate (PC) / Metal Enclosure (IP65)
Compartment Dimension (mm):
PC (L: 310 x W: 230 x H: 150) / Metal (L: 300 x W: 250 x H: 150)
Compartment Weight (gm):
11,000 / 12,000
Battery Type:
LiFePO4 Lithium Battery
Battery Capacity:
12.8V 24AH / 12.8V 30AH
Battery Warranty:
3 Years
System Controller:
Time Control (4hrs: 100%, 2hrs: 60%, 6hrs: 40%) / Microwave Sensor
Discharge Time:
> 2 Cloudy / Rainy Days
Charge Time:
4.5 - 6 hours (Strong Sunlight)
Operating Temperature (°C):
-20°C to +65°C
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) |
|---|---|---|---|---|---|
| LSLB2P05J-P018E3M | 18W | > 80 | 2,350 | L: 600 x W: 80 x H: 77 | 25 years |
| LSLB2P05J-P021E3M | 21W | > 80 | 2,750 | L: 600 x W: 80 x H: 77 | 25 years |
