Outdoor Lighting > LED Street Light

LED Street Light (Eco Prime Series)

Use Cases :

Industrial | Outdoor | Highway | Compound

Wattage:

40W / 60W / 75W / 95W / 100W / 120W / 150W

Colour Rendering Index:

>70

Beam Angle :

120°

Lumen (lm):

6,800 / 10,200 / 12,750 / 16,150 / 17,000 / 20,400 / 25,500

Luminous Efficacy (lm/w):

170

Material:

Pure Aluminium Die Cast with Clear Tempered Glass Diffuser

Dimension (mm):

L: 580 x W: 235 x H: 155 / L: 630 x W: 270 x H: 155

Weight (gm):

5,500 / 6,000

Ingress Protection (IP):

IP66

Impact Resistance Glass:

IK08

Lifespan (hrs):

60,000

Driver:

Internal - Non Dimming / Dimming + Surge Protection Device (SPD)

Input Voltage:

100 - 240 Vac (50 / 60 Hz)

Power Factor (PF):

> 0.95

Total Harmonic Distortion (THD):

< 11%

NEMA Socket:

7-Pin NEMA ANSI Connector: Support LEMS, LORA, NB-IOT Smart Lighting System (optional)

Part Number	Wattage (W)	Lumen (lm)	Dimension (mm)	Lifespan (hrs)
LSTLCP-AS040N5N	40W	6,800	L: 580 x W: 235 x H: 155	60,000
LSTLCP-AS060N5N	60W	10,200	L: 580 x W: 235 x H: 155	60,000
LSTLCP-AS075N5N	75W	12,750	L: 580 x W: 235 x H: 155	60,000
LSTLCP-AS095N5N	95W	16,150	L: 630 x W: 270 x H: 155	60,000
LSTLCP-AS100N5N	100W	17,000	L: 630 x W: 270 x H: 155	60,000
LSTLCP-AS120N5N	120W	20,400	L: 630 x W: 270 x H: 155	60,000
LSTLCP-AS150N5NG	150W	25,500	L: 630 x W: 270 x H: 155	60,000

Interested in this product?
