LED Strip Bar
Buatan MalaysiaMalaysia BrandIECEE CB SchemeRoHS

LED Strip Bar (12V Series)

Use Cases :

Hospital | Retail | Hospitality | Indoor

Wattage (W):

10W/M / 14W/M

Color Temperature (CCT):

2700 / 3000 / 4000 / 5000 / 6500

Color Rendering Index (CRI):

85

Beam Angle:

120°

Lumen (lm):

900 / 1,200

Luminous Efficacy (lm/w):

90 / 86

Material:

Aluminium Bar Profile + Clear Silicon Coating

Dimension (mm):

L: 1000 x W: 13 x H: 5

Weight (gm):

100

Ingress Protection (IP):

IP44

Lifespan (hrs):

50,000

Driver:

External - 12V Non Dimming / Dimming 1-10V, Phase Cut, DALI

Driver Part Number:

LMW12V-▢▢W

Input Voltage:

12 Vdc

Driver Ingress Protection (IP):

IP20

view more >

Specification

Part Number Wattage (W) CRI Lumen (lm) Dimension (mm) Lifespan (hrs) Driver Part Number
LSB1M12E-A10E3C▢ 10W/M 85 900 L: 1000 x W: 13 x H: 5 50,000 LMW12V-▢▢W
LSB1M12E-A14E3C▢ 14W/M 85 1,200 L: 1000 x W: 13 x H: 5 50,000 LMW12V-▢▢W
