Indoor & Commercial > T8 LED Tube
T8 LED Tube (Eco Elite Plus Series)
Use Cases :
Retail | Office | Industrial | Hospitality
Wattage (W):
8W / 10W / 12W / 14W / 16W
Colour Rendering Index (CRI):
> 85
Beam Angle:
160°
Lumen (lm):
1,350 / 1,800 / 2,100 / 2,400 / 2,700
Luminous Efficacy (lm/w):
169 / 171 / 175 / 180
Material:
Polycarbonate (PC) Milky Diffuser (Option: Clear Diffuser)
Dimension (mm) :
Ø:26 x L: 600mm / Ø:26 x L: 1,200mm
Weight (gm):
117gm / 206gm
Lamp Base:
G13
Ingress Protection (IP):
IP20
Lifespan (hrs):
60,000
Driver:
Internal – Non Dimming (Complied with JKR Spec)
Input Voltage:
220 - 240Vac (50/60 Hz)
Power Factor (PF):
> 0.95
Total Harmonic Distortion (THD):
< 11%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) |
|---|---|---|---|---|---|
| LTV2S-P08ES3EPM☐ | 8W | > 85 | 1,350 | Ø:26mm x L: 600mm | 60,000 |
| LTV8-P10ES3EPM☐ | 10W | > 85 | 1,800 | Ø:26mm x L: 1,200mm | 60,000 |
| LTV8-P12ES3EPM☐ | 12W | > 85 | 2,100 | Ø:26mm x L: 1,200mm | 60,000 |
| LTV8-P14ES3EPM☐ | 14W | > 85 | 2,400 | Ø:26mm x L: 1,200mm | 60,000 |
| LTV8-P16ES3EPM☐ | 16W | > 85 | 2,700 | Ø:26mm x L: 1,200mm | 60,000 |
