Indoor & Commercial > LED Down Light Round
LED Down Light Round (Eco Elite Series)
Use Cases :
Retail | Office | Hospitality | Commercial | Residential
Wattage (W):
8W / 12W / 18W / 21W
Color Rendering Index (CRI):
85
Beam Angle:
120°
Lumen (lm):
1,000 / 1,500 / 2,250 / 2,600
Luminous Efficacy (lm/w):
125
Material:
Aluminium + Polycarbonate (PC) Milky Diffuser
Dimension (mm):
Ø: 145 x H: 30 / Ø: 180 x H: 30 / Ø: 230 x H: 30
Cut Hole Size (mm):
110 / 135 / 190
Weight (gm):
192 / 274 / 426
Ingress Protection (IP):
IP20 / IP44
Lifespan (hrs):
50,000
Driver:
External - Non Dimming
Input Voltage:
220 - 240Vac (50/60 Hz)
Power Factor (PF):
> 0.95
Total Harmonic Distortion (THD):
< 12%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | Cut Hole Size (mm) |
|---|---|---|---|---|---|---|
| LD4-A08REE3P▢ | 8W | 85 | 1,000 | Ø: 145 x H: 30 mm | 50,000 | 110 |
| LD4-A12REE3P▢ | 12W | 85 | 1,500 | Ø: 145 x H: 30 mm | 50,000 | 110 |
| LD6-A15REE3P▢ | 15W | 85 | 1,875 | Ø: 180 x H: 30 mm | 50,000 | 135 |
| LD6-A19REE3P▢ | 19W | 85 | 2,375 | Ø: 180 x H: 30 mm | 50,000 | 135 |
| LD8-A19REE3P▢ | 19W | 85 | 2,375 | Ø: 230 x H: 30 mm | 50,000 | 190 |
| LD8-A21REE3P▢ | 21W | 85 | 2,600 | Ø: 230 x H: 30 mm | 50,000 | 190 |
Interested in this product?
Contact us for more information or request a free on-site consultation using the button below.
