Landscape Lighting > LED Inground Drive Over Light
LED Inground Drive Over Light (Elegant Series)
Use Cases :
Architectural | Outdoor | Landscape | Walkway
Wattage (W):
2W / 5W / 12W
Color Temperature (CCT):
2700 / 3000 / 4000 / 5000
Color Rendering Index (CRI):
85 / 95
Beam Angle:
15° / 25°
Lumen (lm):
80 / 200 / 500
Luminous Efficacy (lm/w):
40 / 40 / 46
Material:
Aluminium Die Cast + Stainless Steel + Tempered Glass Diffuser + ABS Mounting Sleeve Kit
Dimension (mm):
Ø: 42 x H: 72 / Ø: 62 x H: 72 / Ø: 110 x H: 135
Cut Hole Size (mm):
Ø: 38 x H: 72 / Ø: 55 x H: 86 / Ø: 100 x H: 135
Weight (gm):
155 / 266 / 1004
Ingress Protection (IP):
IP65 / IP67
Lifespan (hrs):
50,000
Driver:
External - 24V Non Dimming / Dimming 1-10V / Internal - Non Dimming
Driver Part Number:
LOMW24V-▢▢W / ECOPB20
Input Voltage:
24 Vdc / 220 - 240Vac (50/60 Hz)
Driver Ingress Protection (IP):
IP67 / IP65
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | Cut Hole Size (mm) |
|---|---|---|---|---|---|---|
| LINGDO1▢SR24E-A02N▢▢▢ | 2 | 85 / 95 | 80 | Ø: 42 x H: 72 | 50,000 | Ø: 38 x H: 72 |
| LINGDO2▢SR24E-A05N▢▢▢ | 5 | 85 / 95 | 200 | Ø: 62 x H: 72 | 50,000 | Ø: 55 x H: 86 |
| LINGDO4▢SRS-A12N▢▢▢ | 12 | 85 / 95 | 500 | Ø: 110 x H: 135 | 50,000 | Ø: 100 x H: 135 |
