Landscape Lighting > LED Underwater Spot Light Surface
LED Underwater Spot Light Surface (Eco Elegant Series)
Use Cases :
Architectural | Outdoor | Landscape | Swimming Pool | Public
Wattage (W):
8W / 10W
Color Temperature (CCT):
RGB
Color Rendering Index (CRI):
85 / 95
Beam Angle:
25° / 30°
Lumen (lm):
700 / 900
Luminous Efficacy (lm/w):
88 / 90
Material:
Stainless Steel + Tempered Glass Diffuser
Dimension (mm):
Ø: 82 x H: 180 / Ø: 100 x H: 200
Weight (gm):
450 / 610
Ingress Protection (IP):
IP68
Lifespan (hrs):
50,000
Driver:
External - Non Dimming / External - 24V Non Dimming / Dimming 1-10V
Driver Part Number:
ECOPB20 / LOMW24V-▢▢W
Input Voltage:
50 Vdc / 24 Vdc
Driver Ingress Protection (IP):
IP65 / IP67
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | Driver Part Number |
|---|---|---|---|---|---|---|
| LUSL01R▢E-S08N▢▢▢ | 8 | 85 / 95 | 700 | Ø: 82 x H: 180 | 50,000 | ECOPB20 |
| LUSL02R▢E-S10N▢▢▢ | 10 | 85 / 95 | 900 | Ø: 100 x H: 200 | 50,000 | LOMW24V-▢▢W |
