Landscape Lighting > LED Underwater Spot Light Surface
LED Underwater Spot Light Surface (Eco Elegant Series)
Use Cases :
Architectural | Outdoor | Landscape | Swimming Pool | Public
Wattage (W):
12W / 18W
Color Temperature (CCT):
RGB
Color Rendering Index (CRI):
85 / 95
Beam Angle:
25° / 30° / 45°
Lumen (lm):
900 / 1,500
Luminous Efficacy (lm/w):
75 / 83
Material:
Stainless Steel + Tempered Glass Diffuser
Dimension (mm):
Ø: 100 x H: 200 / Ø: 145 x H: 110
Weight (gm):
610 / 950
Ingress Protection (IP):
IP68
Lifespan (hrs):
50,000
Driver:
External - Non Dimming / External - 24V Non Dimming / Dimming 1-10V
Driver Part Number:
LOMW24V-▢▢W
Input Voltage:
24 Vdc
Driver Ingress Protection (IP):
IP20 / IP67
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | Driver Part Number |
|---|---|---|---|---|---|---|
| LUSL01R▢E-S08N▢▢▢ | 8 | 85 / 95 | 700 | Ø: 82 x H: 180 | 50,000 | ECOPB20 |
| LUSL02R▢E-S10N▢▢▢ | 10 | 85 / 95 | 900 | Ø: 100 x H: 200 | 50,000 | LOMW24V-▢▢W |
| LUSL02R24E-S12N25▢ | 12 | 85 / 95 | 900 | Ø: 100 x H: 200 | 50,000 | LOMW24V-▢▢W |
| LUSL03R24E-S18N25▢ | 18 | 85 / 95 | 1,500 | Ø: 145 x H: 110 | 50,000 | LOMW24V-▢▢W |
