Landscape Lighting > LED Inground Uplight Linear Batten
LED Inground Uplight Linear Batten (Elegant Series)
Use Cases :
Architectural | Commercial | Outdoor | Landscape
Wattage (W):
15W / 50W
Color Temperature (CCT):
RGB
Color Rendering Index (CRI):
85 / 95
Beam Angle:
15° / 25° / 40° / 60°
Lumen (lm):
1,400 / 4,500
Luminous Efficacy (lm/w):
93 / 90
Material:
Aluminium Die Cast + Stainless Steel Cover + Tempered Glass + Recessed Kit
Dimension (mm):
L: 1050 x W: 90 x H: 90 / L: 1620 x W: 90 x H: 90
Cut Hole Size (mm):
L: 1010 x W: 65 x H: 90 / L: 1580 x W: 65 x H: 90
Weight (gm):
5800 / 7500
Ingress Protection (IP):
IP65
Lifespan (hrs):
50,000
Driver:
Internal - Non Dimming / External - Non Dimming / Dimming 1-10V
Driver Part Number:
ECOPB20 / LOMW24V-▢▢W
Input Voltage:
220-240Vac (50/60 Hz) / 24 Vdc
Driver Ingress Protection (IP):
IP65 / IP67
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | Cut Hole Size (mm) |
|---|---|---|---|---|---|---|
| LINGB1MS-A15N▢▢▢ | 15 | 85 / 95 | 1,400 | L: 1050 x W: 90 x H: 90 | 50,000 | L: 1010 x W: 65 x H: 90 |
| LINGB15M24E-A50N▢▢▢ | 50 | 85 / 95 | 4,500 | L: 1620 x W: 90 x H: 90 | 50,000 | L: 1580 x W: 65 x H: 90 |
Interested in this product?
Contact us for more information or request a free on-site consultation using the button below.
