Landscape Lighting > LED Uplighter
LED Uplighter (Eco Elegant Series)
Use Cases :
Architectural | Outdoor | Public
Wattage (W):
20W / 30W / 50W / 80W / 120W /150W / 200W
Color Temperature (CCT):
RGB
Color Rendering Index (CRI):
85 / 95
Beam Angle:
15° / 25° / 40° / 60°
Lumen (lm):
1,800 / 2,850 / 4,500 / 8,000 / 12,000
Luminous Efficacy (lm/w):
90 / 95 / 90/ 100 / 100
Material:
Aluminium Die Cast + Tempered Glass Diffuser
Dimension (mm):
Ø: 150 x H: 135 / Ø: 180 x H: 230 / Ø: 200 x H: 260 / Ø: 240 x H: 290 / Ø: 290 x H: 330
Weight (gm):
1000 / 1400 / 1800 / 2500 / 3300
Ingress Protection (IP):
IP65
Lifespan (hrs):
50,000
Driver:
Internal - Non Dimming
Driver Part Number:
ECOPB20 / LOMW24V-▢▢W
Input Voltage:
220 - 240Vac (50/60 Hz) / 24 Vdc
Driver Ingress Protection (IP):
IP65
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | Driver Part Number |
|---|---|---|---|---|---|---|
| LUL01RS-A12N▢▢▢ | 12 | 85 / 95 | 900 | Ø: 130 x H: 115 | 50,000 | ECOPB20 |
| LUL06R▢-A45N▢▢▢ | 45 | 85 / 95 | 4,000 | Ø: 235 x H: 300 | 50,000 | LOMW24V-▢▢W |
| LUL03RS-A20N▢▢▢ | 20 | 85 / 95 | 1,800 | Ø: 150 x H: 135 | 50,000 | ECOPB20 / LOMW24V-▢▢W |
| LUL04RS-A30N▢▢▢ | 30 | 85 / 95 | 2,850 | Ø: 180 x H: 230 | 50,000 | ECOPB20 / LOMW24V-▢▢W |
| LUL05R▢-A50N▢▢▢ | 50 | 85 / 95 | 4,500 | Ø: 200 x H: 260 | 50,000 | ECOPB20 / LOMW24V-▢▢W |
| LUL07R▢-A80N▢▢▢ | 80 | 85 / 95 | 8,000 | Ø: 240 x H: 290 | 50,000 | ECOPB20 / LOMW24V-▢▢W |
| LUL07R▢-A120N▢▢▢ | 120 | 85 / 95 | 12,000 | Ø: 290 x H: 330 | 50,000 | ECOPB20 / LOMW24V-▢▢W |
Interested in this product?
Contact us for more information or request a free on-site consultation using the button below.
