Landscape Lighting > LED Underwater Light Recess
LED Underwater Light Recess (Elegant Series)
Use Cases :
Architectural | Outdoor | Landscape | Swimming Pool | Public
Wattage (W):
2W / 5W / 12W / 15W
Color Temperature (CCT):
RGB
Color Rendering Index (CRI):
85 / 95
Beam Angle:
15° / 25° / 40° / 60°
Lumen (lm):
120 / 280 / 750 / 1,000
Luminous Efficacy (lm/w):
60 / 56 / 63 / 67
Material:
Stainless Steel + Tempered Glass Diffuser + ABS Mounting Sleeve Kit
Dimension (mm):
Ø: 52 x H: 85 / Ø: 62 x H: 90 / Ø: 110 x H: 150 / Ø: 150 x H: 105
Cut Hole Size (mm):
Ø: 46 x H: 80 / Ø: 55 x H: 86 / Ø: 100 x H: 145 / Ø: 134 x H: 100
Weight (gm):
160 / 170 / 750 / 800
Ingress Protection (IP):
IP68
Lifespan (hrs):
50,000
Driver:
External - Non Dimming / Dimming 1-10V
Driver Part Number:
LOMW24V-▢▢W
Input Voltage:
24 Vdc
Driver Ingress Protection (IP):
IP67
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | Cut Hole Size (mm) |
|---|---|---|---|---|---|---|
| LINGUW2R24E-S02N▢▢▢ | 2 | 85 / 95 | 120 | Ø: 52 x H: 85 | 50,000 | Ø: 46 x H: 80 |
| LINGUW3R24E-S05N▢▢▢ | 5 | 85 / 95 | 280 | Ø: 62 x H: 90 | 50,000 | Ø: 55 x H: 86 |
| LINGUW6R24E-S12N▢▢▢ | 12 | 85 / 95 | 750 | Ø: 110 x H: 150 | 50,000 | Ø: 100 x H: 145 |
| LINGUW7R24E-S15N▢▢▢ | 15 | 85 / 95 | 1,000 | Ø: 150 x H: 105 | 50,000 | Ø: 134 x H: 100 |
