Facade Lighting > LED Recessed Step Light
LED Recessed Step Light (Elegant Series)
Use Cases :
Architectural | Commercial | Outdoor | Facade
Wattage (W):
5W / 10W / 12W / 20W
Color Temperature (CCT):
2700 / 3000 / 4000 / 5000
Color Rendering Index (CRI):
85 / 95
Beam Angle:
30°
Lumen (lm):
380 / 550 / 800 / 1,200
Luminous Efficacy (lm/w):
76 / 55 / 67 / 60
Material:
Aluminium Die Cast + Tempered Glass Diffuser + ABS Mounting Sleeve Kit
Dimension (mm):
L: 145 x W: 70 x H: 55 / L: 165 x W: 100 x H: 65 / L: 230 x W: 195 x H: 100 / L: 320 x W: 105 x H: 95
Cut Hole Size (mm):
L: 142 x W: 70 x H: 60 / L: 160 x W: 95 x H: 80 / L: 220 x W: 190 x H: 110 / L: 295 x W: 75 x H: 105
Weight (gm):
150 / 250 / 360 / 300
Ingress Protection (IP):
IP65
Lifespan (hrs):
50,000
Driver:
Internal - Non Dimming
Input Voltage:
220 - 240Vac (50/60 Hz)
Power Factor (PF):
> 0.90
Total Harmonic Distortion (THD):
< 12%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | Cut Hole Size (mm) |
|---|---|---|---|---|---|---|
| LRSL01RSS-A05N3P▢ | 5 | 85 / 95 | 380 | L: 145 x W: 70 x H: 55 | 50,000 | L: 142 x W: 70 x H: 60 |
| LRSL02RSS-A10N3P▢ | 10 | 85 / 95 | 550 | L: 165 x W: 100 x H: 65 | 50,000 | L: 160 x W: 95 x H: 80 |
| LRSL03RSS-A12N3P▢ | 12 | 85 / 95 | 800 | L: 230 x W: 195 x H: 100 | 50,000 | L: 220 x W: 190 x H: 110 |
| LRSL05RSS-A20N3P▢ | 20 | 85 / 95 | 1,200 | L: 320 x W: 105 x H: 95 | 50,000 | L: 295 x W: 75 x H: 105 |
Interested in this product?
Contact us for more information or request a free on-site consultation using the button below.
