Facade Lighting > LED Surface Wall Updown Light
LED Surface Wall Updown Light (Elegant Series)
Use Cases :
Architectural | Commercial | Outdoor | Facade
Wattage (W):
2 x 12W / 2 x 18W / 2 x 15W / 2 x 18W / 2 x 20W
Color Temperature (CCT):
1800 / 2200 / 2700 / 3000 / 4000 / 5000
Color Rendering Index (CRI):
85 / 95
Beam Angle:
40° / 60°
Lumen (lm):
2 x 800 / 2 x 1,300 / 2 x 1,150 / 2 x 1,500 / 2 x 1,800
Luminous Efficacy (lm/w):
67 / 72 / 77 / 83 / 90
Material:
Aluminium Die Cast + Tempered Glass Diffuser
Dimension (mm):
Ø: 65 x H: 200 / Ø: 100 x H: 250 / Ø: 120 x H: 300 / Ø: 160 x H: 450 / Ø: 200 x H: 500
Weight (gm):
700 / 1000 / 1300 / 1800 / 2000
Ingress Protection (IP):
IP65
Lifespan (hrs):
50,000
Driver:
Internal - Non Dimming
Input Voltage:
220 - 240Vac (50/60 Hz)
Power Factor (PF):
0.95
Total Harmonic Distortion (THD):
< 12%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | IP |
|---|---|---|---|---|---|---|
| LSWLUD1RS-A12C▢▢▢ | 2 x 12W | 85 / 95 | 2 x 800 | Ø: 65 x H: 200 | 50,000 | IP65 |
| LSWLUD2RS-A18C▢▢▢ | 2 x 18W | 85 / 95 | 2 x 1,300 | Ø: 100 x H: 250 | 50,000 | IP65 |
| LSWLUD3RS-A09C▢▢▢ | 2 x 9W | 85 / 95 | 2 x 680 | Ø: 90 x H: 260 | 50,000 | IP65 |
| LSWLUD4RS-A15C▢▢▢ | 2 x 15W | 85 / 95 | 2 x 1,150 | Ø: 110 x H: 300 | 50,000 | IP65 |
| LSWLUD4RS-A24C▢▢▢ | 2 x 12 | 85 / 95 | 2 x 800 | Ø: 65 x H: 200 | 50,000 | IP65 |
| LSWLUD4RS-A36C▢▢▢ | 2 x 18 | 85 / 95 | 2 x 1,300 | Ø: 100 x H: 250 | 50,000 | IP65 |
| LSWLUD4RS-A30C▢▢▢ | 2 x 15 | 85 / 95 | 2 x 1,150 | Ø: 120 x H: 300 | 50,000 | IP65 |
| LSWLUD4RS-A36C▢▢▢ | 2 x 18 | 85 / 95 | 2 x 1,500 | Ø: 160 x H: 450 | 50,000 | IP65 |
| LSWLUD4RS-A40E60C▢ | 2 x 20 | 85 / 95 | 2 x 1,800 | Ø: 200 x H: 500 | 50,000 | IP65 |
Interested in this product?
Contact us for more information or request a free on-site consultation using the button below.
