Facade Lighting > LED Surface Wall Light
LED Surface Wall Light (Elegant Series)
Use Cases :
Architectural | Outdoor | Facade
Wattage (W):
5W / 8W / 12W / 2 x 12W
Color Temperature (CCT):
2700 / 3000 / 4000 / 5000
Color Rendering Index (CRI):
85 / 95
Beam Angle:
30° / 45° / 60°
Lumen (lm):
380 / 380 / 820 / 2 x 850
Luminous Efficacy (lm/w):
76 / 48 / 68 / 71
Material:
Aluminium Die Cast + Tempered Glass Diffuse
Dimension (mm):
L: 90 x W: 70 x H: 80 / L: 200 x W: 90 x H: 55 / L: 200 x W: 120 x H: 60 / L: 90 x W: 80 x H: 150
Weight (gm):
1449 / 527 / 839 / 945
Ingress Protection (IP):
IP65
Lifespan (hrs):
50,000
Driver:
Internal - Non Dimming
Input Voltage:
220 - 240Vac (50/60 Hz)
Power Factor (PF):
> 0.90
Total Harmonic Distortion (THD):
< 12%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | IP |
|---|---|---|---|---|---|---|
| LSWL01RSS-A08E3P▢ | 8 | 85 / 95 | 380 | L: 200 x W: 90 x H: 55 | 50,000 | IP65 |
| LSWL02RSS-A12N3P▢ | 12 | 85 / 95 | 820 | L: 200 x W: 120 x H: 60 | 50,000 | IP65 |
| LSWLUD05SS-A12C▢▢▢ | 2 x 12W | 85 / 95 | 2 x 850 | L: 90 x W: 80 x H: 150 | 50,000 | IP65 |
| LSWL06RSS-A05C▢▢▢ | 5 | 85 / 95 | 380 | L: 90 x W: 70 x H: 80 | 50,000 | IP65 |
