Indoor & Commercial > PLL LED Tube
PLL LED Tube (Eco Premiere Series)
Use Cases :
Retail | Office | Industrial | Hospitality | Commercial
Wattage (W):
16W
Color Temperature (CCT):
3000 / 4000 / 5000 / 6500
Color Rendering Index (CRI):
85
Beam Angle:
120°
Lumen (lm):
2,300
Luminous Efficacy (lm/w):
144
Material:
Half Aluminium + Half Polycarbonate (PC) Milky Diffuser (Option: Clear Diffuser)
Dimension (mm):
L: 415 x W: 43 x H: 23
Weight (gm):
195
Lamp Base:
2G11 4Pin
Ingress Protection (IP):
IP20
Lifespan (hrs):
50,000
Driver:
External - Non Dimming / Dimming 1-10V, Phase Cut, DALI
Driver Part Number:
LLD38W700▢
Input Voltage:
220 - 240Vac (50/60 Hz)
Power Factor (PF):
> 0.90
Total Harmonic Distortion (THD):
< 20%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | Driver Part Number |
|---|---|---|---|---|---|---|
| LPLL-A16E3M▢ | 16 | 85 | 2,300 | L: 415 x W: 43 x H: 23 | 50,000 | LLD38W700▢ |
