PLL LED Tube
SIRIMSuruhanjaya TenagaBuatan MalaysiaMalaysia BrandIECEE CB SchemeRoHS

PLL LED Tube (Eco Master Plus Series)

Use Cases :

Hospital | Restaurant | Retail | Office | Hospitality

Wattage (W):

12W

Color Temperature (CCT):

3000 / 4000 / 5000 / 6500

Color Rendering Index (CRI):

85

Beam Angle:

120°

Lumen (lm):

1,900

Luminous Efficacy (lm/w):

158

Material:

Half Aluminium + Half Polycarbonate (PC) Milky Diffuser (Option: Clear Diffuser)

Dimension (mm):

L: 415 x W: 43 x H: 23

Weight (gm):

195

Lamp Base:

2G11 4Pin

Ingress Protection (IP):

IP20

Lifespan (hrs):

50,000

Driver:

External - Non Dimming / Dimming 1-10V, Phase Cut, DALI

Driver Part Number:

ECOPB20

Input Voltage:

220 - 240Vac (50/60 Hz)

Power Factor (PF):

> 0.90

Total Harmonic Distortion (THD):

< 12%

view more >

Specification

Part Number Wattage (W) CRI Lumen (lm) Dimension (mm) Lifespan (hrs) Driver Part Number
LPLLSE-A12E3PM▢ 12 85 1,900 L: 415 x W: 43 x H: 23 50,000 ECOPB20
