LED High Mast / Flood Light / High Bay (Premium Series)
Use Cases :
Industrial | Outdoor | Highway | Compound
Wattage (W):
100W / 150W / 200W / 250W / 300W / 400W / 450W
Color Rendering Index (CRI):
> 70
Beam Angle:
15° / 30° / 60° / 90° / 120° / Asymmetrical
Lumen (lm):
18,000 / 27,000 / 36,000 / 45,000 / 54,000 / 72,000 / 81,000
Luminous Efficacy (lm/w):
180
Material:
Pure Aluminium Die Cast with Clear Tempered Glass Diffuser
Dimension (mm):
L: 330 x W: 200 x H: 175 / L: 440 x W: 235 x H: 190 / L: 560 x W: 330 x H: 245
Weight (gm):
4,500 / 6,500 / 11,500
Ingress Protection (IP):
IP66
Impact Resistance Glass:
IK08
Lifespan (hrs):
60,000
Driver:
External - Non Dimming / Dimming + Surge Protection Device (SPD)
Input Voltage:
100 - 240Vac (50/60 Hz)
Power Factor (PF):
> 0.95
Total Harmonic Distortion (THD):
< 12%
Specification
| Part Number | Wattage (W) | CRI | Lumen (lm) | Dimension (mm) | Lifespan (hrs) | IP | Weight (gm) |
|---|---|---|---|---|---|---|---|
| LHML - A100PN5G▢ | 100W | > 70 | 18,000 | L: 330 x W: 200 x H: 175 mm | 60,000 | IP66 | 4,500 |
| LHML - A150PN5G▢ | 150W | > 70 | 27,000 | L: 330 x W: 200 x H: 175 mm | 60,000 | IP66 | 4,500 |
| LHML - A200PN5G▢ | 200W | > 70 | 36,000 | L: 440 x W: 235 x H: 190 mm | 60,000 | IP66 | 6,500 |
| LHML - A250PN5G▢ | 250W | > 70 | 45,000 | L: 440 x W: 235 x H: 190 | 60,000 | 6,500 | |
| LHML - A300PN5G▢ | 300W | > 70 | 54,000 | L: 560 x W: 330 x H: 245 mm | 60,000 | IP66 | 11,500 |
| LHML - A400PN5G▢ | 400W | > 70 | 72,000 | L: 560 x W: 330 x H: 245 mm | 60,000 | IP66 | 11,500 |
| LHML - A450PN5G▢ | 450W | > 70 | 81,000 | L: 560 x W: 330 x H: 245 mm | 60,000 | IP66 | 11,500 |
Interested in this product?
Contact us for more information or request a free on-site consultation using the button below.
