Wattage (W):

60W / 80W / 100W / 120W / 150W / 200W

Colour Rendering Index (CRI):

> 70

Beam Angle:

60° / 90° / 120°

Lumen (lm):

9,600 / 12,800 / 16,000 / 19,200 / 24,000 / 32,000

Luminous Efficacy (lm/w):

160

Light Material:

Aluminium Die Cast with Tempered Glass Diffuser

Light Dimension (mm):

L: 300 x W: 220 x H: 50 / L: 370 x W: 260 x H: 55 / L: 380 x W: 310 x H: 55 / L: 450 x W330 x H: 55

Light Weight (gm):

1,300 / 1,900 / 2,400 / 3,200

Ingress Protection (IP):

IP66

Impact Resistance Glass:

IK08

Lifespan (hrs):

60,000

Solar Panel Type:

High Efficiency Monocrystalline Silicon

Maximum Power (W):

36V 160W / 36V 160W / 36V 160W / 36V 200W / 36V 240W / 36V 300W

Integrated Compartment (mm):

L: 1235 x W: 705 x H: 96 / L: 1480 x W: 705 x H: 96 / L: 1760 x W: 705 x H: 96 / L: 1640 x W: 905 x H: 125

Solar Lifespan:

25 Years

Integrated Compartment Weight (kg):

37.5kg / 37.5kg / 44kg / 46kg / 50kg / 60.8kg

Battery Type:

LiFeP04 Lithium Battery

Battery Capacity :

25.6V 60AH / 25.6V 60AH / 25.6V 90AH / 25.6V 90AH / 25.6V 114AH / 25.6V 150AH

System Controller:

Time Control ( 4hrs: 100%, 2hrs: 60%, 6hrs: 40% ) / Microwave Sensor

Discharge Time:

12 Hours ( Autonomy ≥ 2 Cloudy / Rainy Days )

Charge Time:

4.5 - 6 hours (Strong Sunlight)

Operating Temperature (°C):

-20°C to +65°C

Mounting Height (m):

4 – 7m / 5 – 8m / 5 – 9m / 8 – 10m / 10 – 12m / 10 – 12m

Pole Spigot Diameter (Ø: mm):

65 / 89mm (Galvanized Pole) / 140mm (Concrete Pole)

Optional Smart Solar Controller:

4-Pin RS485 MPPT Connector: Support LEMS, LORA, NB-IoT Smart Lighting System (Optional)
